8-channel universal indicator - IN 4896
This 4 or 8-channel display offers great flexibility of use All inputs are configurable in a wide range. The integrated 8-bit microcontroller with its 24-bit sigma-delta converter ensures high precision, stability and signal processing speed. Thanks to the high sampling rate on the different channels, this high-level display is ideal for transmitting signals to a recorder, so that all inputs can be recorded at the same time.
Selectable input ranges: Low level voltage DC mV :  ±60 mV > 100 MΩ ±150 mV > 100 MΩ ±300 mV > 100 MΩ ±1,200 mV > 100 MΩ Current/Voltage PM : 0...20 mA < 400 mV I input 4...20 mA < 400 mV I input ±2 V 1 MΩ U input ±5 V 1 MΩ U input ±10 V 1 MΩ Input U ±40 V 1 MΩ U input OHM resistor : 0...100 Ω 0...1 kΩ 0...10 kΩ 0...100 kΩ Connection: 2, 3 or 4 wires Pt 100/500/1 000 Ω, Connection: 2, 3 or 4 wires Ni 1 000/10 000 Thermocouples : J (Fe-CuNi) -200°...900°C K (NiCr-Ni) -200°...1300°C T (Cu-CuNi)-200°...400°C E (NiCr-CuNi) -200°...690°C B (PtRh30-PtRh6) 300°...1,820°C S (PtRh10-Pt) -50°...1 760°C R (Pt13Rh-Pt) -50°...1 740°C N (Omegalloy) -200°...1 300°C L (Fe-CuNi)-200°...900°C Power supply for linear potentiometers

8-channel universal indicator - IN 4896

Reference : IN 4896 following I FP 2115
Availability : tracked stock
Downloads :
• FR - Technical data Download file
