| PARAMETERS | VALUES |
| Measurement uncertainty CALIB100 | 0.2 % of the final measurement (for measurement ranges > 0 ... 200 Pa/± 200 Pa) or 0.5 % of final measurement (for measurement ranges ≤ 0 ... 200 Pa/± 200 Pa) |
| Measurement uncertainty CALIB200 | 0.1 % of final value (for measurement ranges > 0 ... 200 Pa/± 200 Pa) or 0.2 % of final value (for measuring ranges 0 ... 200 Pa/± 200 Pa) or 0.3 % of final value (for measuring ranges 0 ... 100 Pa/± 100 Pa) |
| Hysteresis | 0.1 % of final value |
| Overload capacity | 600 kPa (for measuring ranges > 3 kPa) 200 times (for measuring ranges ≤ 3 kPa) |
| Zero-point thermal drift | ± 0% (zero point cyclic correction) |
| Influence of temperature (margin) | CALIB100 : 0.04 % of final value / K (10 ... 40 °C) CALIB200 : 0.03 % of final value / K (10 ... 40 °C) |
| Calibration temperature | 22 °C |
| Fluids | Air, all non-aggressive gases |
| Measurement input / Power supply | 0 ... 10 V, 0/4 ... 20 mA Measurement accuracy: 0.2 % of final value 24 VDC / 100 mA |
| Display | Alphanumeric display with 2 x 20 characters, backlit |
| Operating temperature | 10 ... 40 °C |
| Storage temperature | -10 ... 70 °C |
| Weight | Approx. 4.5 kg |
| Pressure connections | Ø6 mm for DN 5 mm pipe |
| Certifications | CE |
