| PARAMETERS | VALUES |
| Measurement uncertainty | 0.2 % of final value ± 1 digit for measuring range 1 ... 50 kPa or 0.5 % of final value ± 1 digit |
| Hysteresis | 0.1 % of final value |
| Zero-point thermal drift | None Key reset |
| Influence of temperature (margin) | 0.04 % of final value / K (10 ... 40 °C) |
| Calibration temperature | 22 °C |
| Fluids | Air, all non-aggressive gases |
| Displacement volume | Approx. 100 cm3 (1, 10, 10 kPa) Approx. 200 cm3 (100 Pa) |
| Analog output | 0 ... 1 V (RL ≥ 2 kΩ) 2 Ø4 mm sockets |
| Screen | Liquid crystal display, 4.5 digits (digit height 10 mm) |
| Time constant | 0.1 / 1 s (switchable) |
| Operating temperature | 10 ... 40 °C |
| Storage temperature | -10 ... 70 °C |
| Power supply | 9 V NiCd battery and mains supply |
| Weight | Approx. 4 kg |
| Pressure connections | For DN 6 mm pipe |
| Certifications | CE |
Do you have a project in the design phase? Are you looking for measurement solutions tailored to your technical and regulatory requirements? Contact us to discuss your requirements or get a quote.
Our quality system is ISO 9001 and EN 9100 certified, guaranteeing controlled processes to meet industry standards.
In compliance with the main standards: DO 160, MIL-STD, AMS 2750, we guarantee optimum reliability in the most extreme environments.
Each component is identified by batch and serial number. We keep all material certificates and conformity documents for full traceability.
