The ultra-practical, portable display that accompanies you wherever you go to measure force, weight and pressure.

The PNFO PSDS portable display is ideal for all your strain gage-based measurements, such as load cells, weighing and pressure transducers!

• Practicalitiesit is ultra-compact (17 x 9.3 x 4cm) and slips easily into a pocket or bag. Its design ergonomic offers an excellent grip, thanks to its rounded shape, and a very good shock resistance. From mounting accessories can be added to the unit's ease of use (carrying case, wall or magnet mounting, etc.). Two AA batteries are all you need.

• Data visualization: six display modes possible on a backlit display (128×64 pixels), the PNFO PSDS provides a clear display of measurement data.

• Taking measurementsThey are based on strain gage bridges such as load cells / tension / compression and pressure transducers with a sensitivity up to +/- 480 mV/V. Visit six calibration ranges available for different charging modes (tension and compression) or various sensors. Each calibration range will remember the customizable settings (such as selected units, tare values...). From numerous units available with automatic scaling. Simple configuration (e.g. 2-point calibration) is possible via the keyboard, while the USB port enables complex configuration and calibration with linearization table, backup and restore, as well as real-time connection for curve recording.

Depending on customer requirements, Mesurex can pair any of its load cells or pressure transducers., and calibrate accordingly, to provide a complete measurement system.

If you're in need of a fast, easy-to-use display device, contact us and we'll work out a tailor-made solution for you: me*****@*****ex.fr
